1270nm-1610nm 7mW coaxial DFB uncooled coaxial laser CWDM
parameter:
Wavelength: 1270nm .1410nm .1430nm.1450nm. 1470nm.1490nm.1550nm.1610nm
Output power:7mW
Fiber specification: single mode Fiber
Monitor current:1mA，
Operating Voltage:1.5V
Fiber connection: FC/APC.
Chip type: DFB
1. Features:
Coaxial pigtail package;
Built-in InGaAs/PIN display;
Integrated opto-isolators;
Operating temperature range: -20 ~ 80°C.
2. Application:
CDMA/GSM transmission system;
WDM system;
CATV backhaul path;
Other analog transmission systems.
