450nm 80W Laser Module with Air Assist Laser Engraver Head for Laser Engraving Cutting Machine Wood Working Tools Laser Head
- Model Number: Laser Head Focusing Metal Fixed Mounting
- Certification: CE,FCC
- 12V ZBAITU C80-EAIR: 80W Laser Module Kit
- 10W Optical Diode Laser Module: for DIY Metal Wood Leather Acrylic Glass
- 10W Laser Head: Compatible Most Laser Engraving Cutting Machine
Product Specification
Model ：C40-EAIR/C80-EAIR
Heatsink Material：Aircraft Aluminum + Brass Shell
Luminous Color：Blue
Cooling Mode：Temperature sensor intelligent control + 10000 rpm 40mm cooling fan
Dimension ：4x4x12 CM
Can Cut/Engrave : MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum/PVC
Module Input：40-80W
Optical power output ：4.5-5.8W/9.5-11.8W
Wavelength ：450nm
Beam Shape ：0.08X0.08mm
TTL&PWM Modulation：YES, Compatible with Both TTL & PWM Modulation
PWM/TTL Input ：DC3.3V-12V
Drive Mode：External ACC
Safe temperature range：<60 ℃
Module weight ：200g ( The lighter the weight, the smaller the move inertia, the better the performance )
Life Time：10000 hours
Features
