457nm 8W -30W semiconductor high-power laser DPSS adjustable power supply can be coupled with fiber coupling
pecifications
Model No:LSR457CP
Wavelength:457+/-2nm
Output Power(average): >8W-30W
Spatial Mode: Multimode
Spectral Linewidth:2nm
Operation Mode: CW or Modulation
Beam Size: :6mm
Beam Divergence (full angle): <1.2 mrad
Beam Height :34mm
Power Stability*:<3% per 4 hrs
Warm Up Time:<1 minutes
Beam Quality m2:<2
Optimum Operating Temperature :20~30oc
Storage Temperature:10~50oC
MTTF** :10,000 hrs
Dimensions :166(L)x120(W)x45.5(H) mm
Adjustable power supply:LSR-PS-FA:178(W)x197(D)x84(H) mm3
